RackStation RS2421+
฿80,547 Include VAT.
12 เบย์
AMD Ryzen V1500B, 4-core 2.2 GHz
ขยายได้ถึง 24 ไดรฟ์
เพิ่มหน่วยความจำได้สูงสุด 32 GB (16Gb x 2)
ติดต่อขอราคาอัพเดท และอัพเดทสต๊อกสินค้า ***
Category: Plus Series
Tag: 12bays
Description
CPU |
CPU Model | AMD Ryzen V1500B |
---|---|---|
CPU Quantity | 1 | |
CPU Architecture | 64-bit | |
CPU Frequency | 4-core 2.2 GHz | |
Hardware Encryption Engine (AES-NI) | ||
Memory |
System Memory | 4 GB DDR4 ECC UDIMM |
Memory Module Pre-installed | 4 GB (4 GB x 1) | |
Total Memory Slots | 2 | |
Maximum Memory Capacity | 32 GB (16 GB x 2) | |
Notes |
|
|
Storage |
Drive Bays | 12 |
Maximum Drive Bays with Expansion Unit | 24 (RX1217/RX1217RP x 1) | |
Compatible Drive Type* (See all supported drives) |
|
|
Maximum Single Volume Size* | 108 TB | |
Hot Swappable Drive | ||
Notes |
|
|
External Ports |
RJ-45 1GbE LAN Port | 4 (with Link Aggregation / Failover support) |
USB 3.2 Gen 1 Port* | 2 | |
Expansion Port | 1 | |
Notes | The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019. | |
PCIe |
PCIe Expansion | 1 x Gen3 x8 slot (x4 link) |
File System |
Internal Drives |
|
External Drives |
|
|
Appearance |
Form Factor (RU) | 2U |
Size (Height x Width x Depth) | RS2421+ :88 mm x 482 mm x 552 mmRS2421RP+ :88 mm x 482 mm x 578 mm | |
Weight | RS2421+ :11.5 kgRS2421RP+ :11.9 kg | |
Rack Installation Support* | 4-post 19″ rack (Synology Rail Kit – RKS1317) | |
Notes | The rail kit is sold separately | |
Others |
System Fan | 60 mm x 60 mm x 3 pcs |
Fan Speed Mode |
|
|
Easy Replacement System Fan | ||
Power Recovery | ||
Noise Level* | RS2421+ :50.1 dB(A)RS2421RP+ :54 dB(A) | |
Scheduled Power On / Off | ||
Wake on LAN / WAN | ||
Power Supply Unit / Adapter | RS2421+ :500 WRS2421RP+ :350 W | |
Redundant Power Supply | RS2421+ :–RS2421RP+ : | |
AC Input Power Voltage | 100 V to 240 V AC | |
Power Frequency | 50/60 Hz, Single Phase | |
Power Consumption* | RS2421+ :79.56 W (Access) 34.89 W (HDD Hibernation) RS2421RP+ :91.76 W (Access) 48.21 W (HDD Hibernation) |
|
British Thermal Unit | RS2421+ :271.65 BTU/hr (Access) 119.13 BTU/hr (HDD Hibernation) RS2421RP+ :313.31 BTU/hr (Access) 164.61 BTU/hr (HDD Hibernation) |
|
Notes |
|
|
Temperature |
Operating Temperature | 0°C to 35°C (32°F to 95°F) |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
Relative Humidity | 5% to 95% RH | |
Certification |
|
|
Warranty |
3-year hardware warranty, extendable to 5-year coverage – EW202 |
